DP1000-G5 Automated IC Programming System

Model Name : DP1000-G5
DP1000-G5 Automated IC Programming System is a compact and highly compatible model suitable for a wide range of IC programming needs.
This item is unavailable for online purchase.



Description

DP1000-G5 Automated IC Programming System is the latest generation of DP1000, which supports different input/output peripherals to provide an overall solution for IC chip programming. It supports most of the IC families, such as EEPROM, NAND/NOR FLASH, MCU, eMMC, and UFS, etc.

The system can embed with 2 sets of NuProgPlus Series programmers to provide up to 32 programming sites with stable quality & high throughput. Additionally, the Auto Teach Feature will automatically adjust the parameter to increase productivity.






Features

    High Throughput

  • The system will be able to perform up to 3,000 UPH (Units per Hour)



  High Expansibility

  • Able to embed two sets of NuProgPlus Series programmers (Universal & UFS) to expand up to 32 programming sites.



  Support All IC Families

  • Supported IC: EEPROM, NAND/NOR FLASH, MCU, eMMC, and UFS, etc.
  • Supported IC Package: SOP, SSOP, TSSOP, PLCC, QFN, LQFP, and BGA, etc.
  • Minimum supported size: 1x1mm CSP.



   Adjustable Socket Actuating Kit

  • The adjustable socket actuating kits can easily adjust to fit different types and sizes of sockets without extra socket actuating kits!



   Support Different Input/Output Peripherals

  • Input/Output: Tube, Tape, and Tray.



   Clamp Positioning Check

  • The system will automatically check if the clamps are installed properly before production to avoid machine/product damage caused by unmanned staff mistakes.



   Auto Teach

  • Proceduralize- Automatically adjust the handler's parameters.
  • Digitalized- Automatically adjust the heights of nozzles.
  • Increase the speed of system adjustment.
  • Self-detection Function- Increase the accuracy & stabilities for nozzles' pick and place.



   Software Supports Work Project

  • Able to create a programming file directly through DediWare according to your programming demands. It allows you to start programming right after loading the project, greatly reducing human errors.



  MES (Manufacturing Execution System)

  • DediProg handlers can apply different MES; the production line via API protocol is easily integrated with their internal server. Work reports can be converted to Excel files as records.



    IC Marking Functions, provide a variety of labeling methods

  • Ink Marker supports dots, characters, or numbers.
  • Laser Marker supports precise character marking.
  • Label Printer supports QR codes and barcodes.
  • Label Feeder automatically supplies labels to IC for identification.



Optional Accessories

Chip Programmers

♦ NuProgPlus-S8

 NuProgPlus-S16



I/O Peripherals

Automated Taping Machine

 ♦ DP600-A



Electrical Tape Feeders

 ETF-8mm

 ETF-12mm

 ETF-16mm

 ETF-24mm

 ETF-32mm

 ETF-44mm



Auto Tray Loaders

 Auto Tray-250

 Auto Tray-260

 Auto Tray-350 Series



Manual Tube In/Out Loaders

 MTI-220 (Input)

 MTO-230 (Output)



Others
Ink Marking Systems

 AIM-610 Ink Marker

♦ ALM-610 Laser Marker

 LF-100P2 Label Printer

 ALF-100 Label Feeder



AOI Inspection Systems

 AOI-632 (2D)

 ANS-640-B (2D)



Auto Parameter Calibration

♦ Auto Teach



Socket Adaptors
