DP3000-G3 Plus Automated IC Programming System

Model Name : DP3000-G3 Plus
DP3000-G3 Plus Automated IC Programming System can embed with up to 6 sets of gang Programmers to provide up to 96 programming sites with stable quality & high throughput.
This item is unavailable for online purchase.



Description

The DP3000-G3 Plus Automated Programming System is the latest generation of the DP3000 series, supporting CSP and small-size package programming. The DP3000-G3 Plus offers a variety of input/output peripheral options, including tube, tape, and tray, providing a comprehensive solution for IC programming with advanced features. The system can integrate up to 6 gang programmers, offering a total of 96 programming sites, ensuring stable quality and high throughput. It is particularly suited for programming high-density devices, such as eMMC and UFS, preventing downtime and maximizing production capacity even during long programming cycles.





Features

   High Throughput

  • The system can reach up to 3,300 UPH (Units Per Hour).



  High Expansibility

  • Able to embed six sets of NuProgPlus Series programmers (Universal & UFS) to expand up to 96 programming sites.



  Support All IC Families

  • Supported IC: EEPROM, NAND/NOR FLASH, MCU, eMMC, and UFS, etc.
  • Supported IC Package: SOP, SSOP, TSSOP, PLCC, QFN, LQFP,  BGA, and WLCSP,  etc.
  • Minimum supported size: 1x1mm CSP.



   Adjustable Socket Actuating Kit

  • The adjustable socket actuating kits can easily adjust to fit different types and sizes of sockets without extra socket actuating kits!



   Support Different Input/Output Peripherals

  • Input/Output: Tube, Tape, and Tray.



   Clamp Positioning Check

  • The system will automatically check if the clamps are installed properly before production to avoid machine/product damage caused by unmanned staff mistakes.



   Auto Teach

  • Proceduralize- Automatically adjust the handler's parameters.
  • Digitalized- Automatically adjust the heights of nozzles.
  • Increase the speed of system adjustment.
  • Self-detection Function- Increase the accuracy & stabilities for nozzles' pick and place.



   Software Supports Work Project

  • Able to create a programming file directly through DediWare according to your programming demands. It allows you to start programming right after loading the project, greatly reducing human errors.



  MES (Manufacturing Execution System)

  • DediProg handlers can apply different MES; the production line via API protocol is easy to integrate with their internal server. Work reports can be converted to Excel files as a record.



    IC Marking Functions, provide a variety of labeling methods

  • Ink Marker supports dots, characters, or numbers.
  • Laser Marker supports precise character marking.
  • Label Printer supports QR codes and barcodes.
  • Label Feeder automatically supplies labels to IC for identification.



Optional Accessories

Chip Programmers

♦ NuProgPlus-S8

 NuProgPlus-S16



I/O Peripherals

Automated Taping Machine

 ♦ DP600-A



Electrical Tape Feeders

♦ ETF-8mm

♦ ETF-12mm

 ETF-16mm

 ETF-24mm

 ETF-32mm

 ETF-44mm



Auto Tray Loaders

 Auto Tray-250

♦ Auto Tray-260

 Auto Tray-350 Series



Manual Tube In/Out Loaders

♦ MTI-220 (Input)

 MTO-230 (Output)



Others
Ink Marking Systems

 AIM-610 Ink Marker

 ALM-610 Laser Marker

 LF-100P2 Label Printer

 ALF-100 Label Feeder



AOI Inspection Systems

♦ AOI-63X (2D)

 ANS-640-B (2D)

ANS-68X (3D)



Auto Parameter Calibration

 Auto Teach



Socket Adaptors
